• Automatic reset thermal protector prevents overheating.

• Patented MAXGuard® insulation system offers superior protection for use with a variable frequency drive.

• Permanently lubricated, double-sealed bearings extend the lifetime of the motor.

• Ambient temperature up to 70°C allows for consistent operation in a range of environments and applications.

• Vertical/horizontal mounting for proper placement of the fan within airflow.

             FLA Cat.

HP     RPM     Spds      Volts      Base      Rotation      @ NP

1/2    1140     1     208-230/460    NB         CCW/CW       2.1-2.4/1.2

3/4    1140     1     208-230/460    NB         CCW/CW       3.0-3.4/1.7

1     1140     1     208-230/460    WB         CCW/CW       4.2-4.0/2.0

      1140      1     208-230/460    NB         CCW/CW       4.2-4.0/2.0                         850      1     208-230/460    NB         CCW/CW       5.1-5.2/2.6

1.5   1140      1     208-230/460    WB         CCW/CW       5.1-5.0/2.5                         1140      1     208-230/460    NB         CCW/CW       5.1-5.0/2.5
