Features

• Double sealed ball bearings

• Voltage change device • Internal and external water slingers

• Dripproof enclosure when mounted vertically

• 65° ambient

Applications

Designed for use on outdoor condenser fan and blower units with three phase power available.

                FLA Cat.

HP            RPM     Spds      Volts      Base         Rotation         @ NP

1/2               1140     1     208-230/460     NB         CCW/CW       2.1-2.4/1.2

3/4               1140     1     208-230/460     NB         CCW/CW       3.0-3.4/1.7

1                 1140     1     208-230/460     WB         CCW/CW       4.2-4.0/2.0

        1140      1     208-230/460     NB         CCW/CW       4.2-4.0/2.0

        850     1     208-230/460     NB         CCW/CW       5.1-5.2/2.6

1.5                1140      1     208-230/460    WB         CCW/CW       5.1-5.0/2.5

        1140      1     208-230/460     NB         CCW/CW       5.1-5.0/2.5
